Main features:
The CORE models are Inverter equipment for welding with covered electrodes and TIG, which apply the new Nanocrystaline technology, achieving an unbeatable weight-performance ratio. All this, at an extremely competitive price. Do you want a Solter Inverter? With the new CORE, it's possible.
· New Nanocrystaline technology, smaller, more powerful, lighter
· Easy to use thanks to Inverter technology supplying direct current DC.
· Minimum consumption due to its high energy efficiency.
· Connectable to generators with a wide range of voltages of use.
· Equipped with Arc-Force and Hot-Start devices.
· Possibility of TIG welding.
| General | |
|---|---|
| Duty Cycle at 40ºC | 40% |
| Regulation | 20 - 200A |
| Intensity MAX. | 200A |
| Intensity at 60%(100%) a 40ºC | 160A (135A) |
| Regulations | EN 90791-1, EN 60974-10 |
| Tech | |
| Usable electrodes TIG | 1,0 - 3,2mm |
| Usable electrodes MMA | 1,6mm - 4,0mm |
| Electric | |
| OCV | 69V |
| Voltage range | 190V - 265V |
| Absorved power max. | 6,9Kva |
| Ieff | 25A |
| Fuse | 16A |
| Supply Voltage | 230V - 1Ph |
| Structural | |
| Ventilation | FORZADA |
| Weight | 5.5 kg |
| Regulation board | SOLTER DIGITAL |
| Protection index | IP21S |
| Dimensions | 370x120x210 |
| Technologies | |
| Tecnologies | Anti STICK, Arc Force, Hot-Start, Generator OK |
