Ref. 14012


1,690.00 € 1690.0 EUR Precio con iva: 2044.90 € 1,690.00 €

1,690.00 €

  • Cutting capacity ALUMINIUM
  • Cuttinh capaciity STEEL
  • Cutting capacity STAINLESS STEEL
  • Supply Voltage
  • Dimensions
  • Air flow
  • Protection index
  • Intensity at 60%(100%) a 40ºC
  • Intensity MAX.
  • Weight
  • Absorved power max.
  • Air pressure
  • Regulation
  • Duty Cycle at 40ºC
  • OCV
  • Imax

This combination does not exist.

· 60Amp plasma cutting equipment.
· 400V-3ph connection.
· Cut up to 22mm.
· Complete with ground clamp and torch.

Share this product:

· Highly portable inverter plasma cutting equipment with an impressive power-to-weight ratio.
· With a cutting capacity of up to 22mm, it is the ideal system for industrial manufacturing and metal construction work.
· Cut all kinds of materials such as carbon steel, stainless steel and aluminum.

Intensity at 60%(100%) a 40ºC 48A (38A)
Intensity MAX. 60A
Regulation 10-60A
Duty Cycle at 40ºC 40%
Cutting capacity ALUMINIUM 22mm
Cuttinh capaciity STEEL 22mm
Cutting capacity STAINLESS STEEL 15mm
Air flow 150l/min
Air pressure 3.5-10bar
Supply Voltage 400V - 3ph
Absorved power max. 10Kva
OCV 300V
Imax 14,75A
Dimensions 430x170x270mm
Protection index IP23
Weight 18 Kg
